    Z2 C45 Steel Keyless Shaft Locking Device Assemblies Clamping Elements

    Ask Lasest Price
    Brand Name : XTC
    Model Number : XTC-LD02
    Certification : ISO9001:2015
    Price : Negotiable
    Payment Terms : Western Union, T/T, MoneyGram, L/C
    Supply Ability : 80000pcs per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Z2 C45 Steel Keyless Shaft Locking Device Assemblies Clamping Elements

    Z2 C45 Steel Shaft Locking Device Clamping Elements


    Overiew


    Shaft locking device/clamping elements belong to the category of general mechanical parts and are used to connect two shafts (driving shaft and driven shaft) in different mechanisms to make them rotate together to transmit torque.


    Basic Dimensions and Parameters of Z2 C45 Steel Shaft Locking Device Clamping Elements


    Size (mm)Dimensions (mm)Rated LoadContact PressureLocking Screws (G.12.9)

    Approx Weight

    (KG)

    d x D x LL1L2Axial (KN)Torque (N.m)Shaft (Mpa)Hub (Mpa)Tightening (N.m)

    19 x 47 x 20

    20 x 47 x 20

    22 x 47 x 20

    17

    17

    17

    26

    26

    26

    28

    28

    30

    270

    290

    290

    221

    232

    200

    93

    98

    90

    15

    15

    15

    0.20

    0.22

    0.23

    24 x 50 x 20

    25 x 50 x 20

    28 x 55 x 20

    17

    17

    17

    26

    26

    26

    32

    33

    36

    380

    400

    520

    216

    200

    208

    103

    100

    104

    15

    15

    15

    0.23

    0.23

    027

    30 x 55 x 20

    32 x 60 x 20

    35 x 60 x 20

    17

    17

    17

    26

    26

    26

    37

    43

    44

    520

    690

    770

    183

    209

    196

    99
    112

    113

    15

    15

    15

    0.26

    0.28

    0.30

    38 x 65 x 20

    40 x 65 x 20

    42 x 75 x 24

    17

    17

    20

    26

    26

    32

    49

    49

    74

    940

    980

    1560

    202

    190

    233

    116

    115

    129

    15

    15

    37

    0.33

    0.32

    0.57

    45 x 75 x 24

    48 x 80 x 24

    50 x 80 x 24

    20

    20

    20

    32

    32

    32

    74

    74

    75

    1700

    1830

    1830

    216

    214

    196

    127

    122

    118

    37

    37

    37

    0.55

    0.60

    0.56

    55 x 85 x 24

    60 x 90 x 24

    65 x 95 x 24

    20

    20

    20

    32

    32

    32

    89

    92

    99

    2490

    2640

    3240

    218

    192

    202

    140

    126

    136

    37

    37

    37

    0.65

    0.66

    0.72

    70 x 110 x 28

    75 x 115 x 28

    80 x 120 x 28

    24

    24

    24

    38

    38

    38

    124

    135

    137

    4700

    4800

    5400

    218

    185

    185

    135

    119

    124

    70

    70

    70

    1.27

    1.33

    1.35

    85 x 125 x 28

    90 x 130 x 28

    95 x 135 x 28

    24

    24

    24

    38

    38

    38

    146

    148

    165

    6300

    6500

    7800

    195

    178

    193

    130

    124

    134

    70

    70

    70

    1.45

    1.55

    1.65

    100 x 145 x 33

    105 x 150 x 33

    110 x 155 x 33

    26

    26

    26

    45

    45

    45

    187

    188

    195

    9560

    9750

    10330

    195

    178

    175

    135

    125

    121

    127

    127

    127

    2.20

    2.40

    2.40

    120 x 165 x 33

    125 x 170 x33

    130 x 180 x 38

    26

    26

    34

    45

    45

    50

    210

    210

    279

    12600

    13370

    18030

    176

    175

    167

    128

    121

    116

    127

    127

    127

    2.60

    3.20

    3.60

    140 x 190 x 38

    150 x 200 x 38

    160 x 210 x 38

    34

    34

    34

    50

    50

    50

    296

    326

    351

    20800

    24300

    28100

    162

    168

    168

    123

    124

    129

    127

    127

    127

    3.80

    4.10

    4.50

    170 x 225 x 44

    180 x 235 x 44

    190 x 250 x 52

    38

    38

    46

    58

    58

    66

    392

    435

    502

    33300

    39100

    44700

    163

    172

    155

    119

    131

    120

    195

    195

    195

    5.90

    6.10

    8.50

    200 x 260 x 52

    210 x 275 x 56

    220 x 285 x 56

    46

    50

    50

    66

    72

    72

    522

    605

    640

    51900

    63500

    69900

    150

    157

    158

    116

    121

    122

    195

    300

    300

    9.00

    10.1

    11.0

    240 x 305 x 56

    250 x 315 x 56

    260 x 325 x 56

    50

    50

    50

    72

    72

    72

    703

    737

    840

    84300

    92200

    109200

    162

    158

    172

    127

    125

    140

    300

    300

    300

    12.4

    12.8

    19.3

    280 x 355 x 66

    300 x 375 x 66

    320 x 405 x 78

    60

    60

    72

    84

    84

    98

    870

    974

    1312

    122100

    145900

    212600

    143

    147

    157

    114

    119

    126

    410

    410

    590

    21.1

    21.5

    29.8

    340 x 425 x 78

    360 x 455 x 90

    380 x 475 x 90

    72

    84
    84

    98

    112

    112

    1338

    1560

    1633

    222800

    296700

    300600

    149

    153

    134

    119

    122

    115

    590

    790

    790

    30.0

    43.5

    46.5

    400 x 495 x 90

    420 x 515 x 90

    440 x 545 x 102

    84

    84

    96

    112

    112

    126

    1668

    1830

    1980

    325100

    385200

    441400

    136

    136

    126

    111

    113

    102

    790

    790

    1000

    47.0

    50.0

    65.0


    Drawings of Z2 Clamping Elements



    Materials


    This product is made of C45 steel, a medium carbon high quality steel with high strength, which is generally used in normalised condition due to poor hardenability, and tempered when higher mechanical properties are required. Cold deformation plasticity is medium, annealed and normalized machinability than the tempered good. Used for the manufacture of parts with high strength requirements.


    Tensile strength σb (MPa)≥600(61)
    Yield strength σs (MPa)≥355(36)
    Elongation δ5 (%)≥16
    Section shrinkage ψ (%)≥40
    Impact power Akv (J)≥39
    Impact toughness value αkv (J/cm2)≥49(5)

    Our Factory



    Main Manufacturing Equipment


    Z2 C45 Steel Keyless Shaft Locking Device Assemblies Clamping Elements


    Packing



    Typical Application



    For connecting drives in various machines.
